Outline
DLB Series Multifunction granulation coating machine is a set of granulation coating - fluid coating - fluidized drying multifunctional device. Especially for medicine, food, chemical and other industries more variety granulation coating. Particles prepared instant granules is porous. For dense balls (pills) particles, high true sphericity. Equipment sealing, smooth, no dead ends, easy to operate. The entire process are used to run stand-alone. And complete granulating, pill, coated in the same vacuum sealed container.
Feature
Western granulation - coating;
Chinese medicine extract granulation - coating;
Preparation of porous instant granules.
Technical Parameters
|
Model |
DLB- |
5 |
15 |
30 |
60 |
120 |
200 |
|
The maximum working volume（L） |
Top spray |
22 |
45 |
100 |
220 |
620 |
670 |
|
Bottom spray |
14 |
38 |
102 |
170 |
417 |
620 |
|
|
Electric heating power（KW） |
21 |
27 |
45 |
81 |
135 |
180 |
|
|
Temperature range（℃） |
10-90 |
||||||
|
Steam consumption (KG / h) |
60 |
100 |
180 |
220 |
366 |
400 |
|
|
Induced draft fan power（KW） |
5.5 |
11 |
15 |
22 |
30 |
37 |
|
|
Compressed air consumption (M3 / min) |
0.9 |
0.9 |
0.9 |
1.1 |
1.3 |
1.5 |
|
|
Total Weight |
1450 |
1800 |
2600 |
3450 |
4000 |
4700 |
|
|
Size |
A1 |
A2 |
A3 |
B |
C |
ΦD |
E1 |
E2 |
F
|
G |
|
5 |
3210 |
3210 |
2810 |
2140 |
920 |
500 |
3260 |
2610 |
810
|
740 |
|
15 |
4060 |
4060 |
3660 |
2280 |
970 |
800 |
4100 |
3410 |
1200
|
970 |
|
30 |
4400 |
4400 |
4000 |
2520 |
1130 |
1200 |
4600 |
3750 |
1770
|
1420 |
|
60 |
4800 |
4800 |
4400 |
2900 |
1180 |
1400 |
5000 |
4100 |
2100
|
1620 |
|
120 |
5100 |
5100 |
4700 |
3000 |
1380 |
1500 |
5300 |
4400 |
2100
|
1620 |
|
200 |
5300 |
5300 |
4900
|
3290
|
1670
|
1800
|
5650
|
4600
|
2540
|
1740
|
