Job Description
After purification, the heated air from the annulus into the container, the material showed a high-speed vessel boiling shape, due to the distribution of the rotating plate, the material by its own gravity, air floating circumferential centrifugal force, frictional force, circumferentially surrounding the operating state.
Adhesive or coating agent is sprayed into the material layer, so that the material to form a dense, high sphericity of pellets or continuous uniform coating film.
Feature
Unique distribution plate structure, and continuously adjustable, denser particles, the ball really high degree, suitable for powder particles, particle coating system balls.
structure diagram
 |
 |
Technical Parameters
|
Item \ Specification |
1.5 |
10 |
20 |
30 |
60 |
120 |
|
Working volume |
5 |
30 |
60 |
105 |
180 |
420 |
|
Feeding amount kg / times |
1.5 |
10 |
20 |
30 |
60 |
120 |
|
Rotary power |
0.55 |
1.5 |
4 |
5.5 |
7.5 |
11 |
|
Fan power |
3 |
5.5 |
7.5 |
15 |
18.5 |
11 |
|
Steam consumption |
35 |
42 |
84 |
166 |
250 |
332 |
|
Amount of compressed air |
0.3 |
0.6 |
0.6 |
0.9 |
1.1 |
1.6 |
The data only when selection of reference, our company reserves the right to change the above data, are subject to change without notice.
